Manufacturing superior products begins with careful attention to detail. That’s why US Mezzanines partition systems are made from the highest-quality wire mesh and steel components on the market. USM safegarde partition panels are made of framed 2”x2”x10GA welded wire mesh reinforced with two ½” round bars, which divide the panels into three equal sections. Frames are made of 1 ¼”x1 ¼”x12GA structural angle. Available in a variety of standard and custom sizes for your convenience. Standard line and corner posts are made of 2”x2”x16GA square seam welded tubing, welded to a 6”x6”x1/4” base plate for perfect support and rigidity. Floor-to-ceiling partitions that surpass 24’ are mounted on 3”x3”x10GA posts and welded to 8”x8”x1/4” base plates to ensure sufficient reinforcement.

System 1 features a freestanding post design for partition up to 10’High. All panels are made of frame welded wire mesh with a standard post spacing of 8’ or 10’. Ideal to create a secured perimeter or an office in any warehouse.

System 2 features a freestanding post design for partition up to 24' High and includes framed roof panels for added security. All panels are made of frame welded wire mesh with a standard post spacing of 8' or 10'. The perfect system when you need the highest security level cage for your warehouse needs.

System 3 features a floor to ceiling post design with adjustable ceiling sleeves for uneven surfaces. All panels are made of frame welded wire mesh with a standard post spacing of 8' or 10'. The perfect system when you want a fully enclosed room and use the full height available and still keep the option to install racking and high storage units.
