Every mezzanine project encounters different conditions and requirements, that’s why USM offers various engineering solutions to meet your specific needs. As our standard, each mezzanine comes with a basic plans package that will support you up to certain stage during the different phases of your project.
Depending on the complexity of your project and requirements, USM recommends that most clients and/or end users work in association with an architect for additional support. This is to ensure that any critical aspects such as building classification and occupancy, electricity, plumbing, fire codes, exit signage etc. will be properly analyzed and addressed. Please keep in mind that USM is not responsible for certifying or analyzing the concrete slab capacity and integrity where the mezzanine columns are to be installed.
USM MEZZANINE PE STAMPED PLANS WITH CALCS AND CONNECTION DETAILS PACKAGE INCLUDES (CONTACT FOR PRICING):
INCLUDED:
This package is ideal when you are applying for a permit from the city. Our engineers will prepare specific drawings detailing the different aspects of the mezzanine that are generally required during the permitting process.
Please note that USM is not responsible for any delays encountered during plan check and revisions that may be caused by city regulations. The permits are to be obtained at the purchaser’s expense. Due to the variation of safety codes between regions, it is also the responsibility of the purchaser and/or end user to ensure that the product complies with all respective Electrical, Fire, Seismic, or Safety Codes, that pertain to the use and installation of the mezzanine. The purchaser and/or end user must arrange for the appropriate installation and testing of the USM mezzanine such that all State, Provincial or Local Safety codes are respected.
- 6 copies of the following:
- Stamped structural plan and elevation drawings including design criteria data.
- Mezzanine classification details and compliance including mezzanine location based on information received by client.
- Dimensions of the overall mezzanine as well as columns and beams location, fastener details and dimensions.
* Please note that 1 (one) stamped version is included with this package. Any revisions or modifications after the approval stage might incur additional costs.
- A copy of the engineering calculations.
- Structural drawings including dimensions, design specifications and fastener specifications of the following:
- Bracing
- Column and base plate
- Beam to column connection
- Beam to beam connection
- Bridging
- Flooring
- Staircase
- Handrail
- Installation drawings and procedure supplied on delivery.
Please note that the client and/or end user is responsible for all quantities and dimensions including the verification of, and coordination with field conditions. The client and/or end user is also responsible for the building classification on all construction and warrants that all construction will be governed by the latest edition of the state or provincial building code (including any revisions or addendums) and/or with any other applicable code or requirements of all authorities having jurisdiction. USM mezzanines are designed in compliance with the National Code and the American and Canadian Institute of Steel Construction (NBCC and CISC in Canada and IBC and AISC in the U.S.).
NOT INCLUDED:
- Footing design and anchor design.
